Rev-A-Shelf 14″ Tip-Out Plastic Sink Trays for Kitchen and Bathroom Base Cabinet, Pull Out Vanity Shelf Home Organizer, White, 6572-14-11-52

The instructions that came with the product are not wrong, but I think mine are better and will save you work and swear words… Read my instructions before you start! And read theirs. And decide which will work better for your case.Instructions:Order of assembly:0) Before you start, check the flip-out tray to make sure you will have enough clearance to the sink! If not, make a plan and think it through before you start.1) Mark the CORNERS of the drawer front opening from the inside, IN PENCIL. You will want to erase the pencil marks later! Take the drawer front out. Do NOT remove the plastic or wood clips that hold the drawer front in position verticaly! You will want them later.2) The two hinges are different! One is left, and one is right. Attach the hinges to the face frame inside opening edges, typically aligned to the bottom corners of the opening.3) Put the drawer front back in. Line it up properly side to side, aligned to the door below it.4) From the inside of the cabinet, use a pencil to mark the hole positions in the hinge plate on the drawer front.5) Take the drawer front back out.6) You can remove the old drawer front attachment clips now, since they will interfere in following steps7) If you will add a drawer knob or pull, mark its position now, and drill the holes. Match the height to adjacent drawer pulls! They are not always centered vertically.7) Mark the holes for the flip out tray. Make sure it will clear top and bottom when closed.8) Before you drill the holes, mark the drill bit with a piece of tape to show the required drill depth. Drill the holes for the hinges and the flip-out tray. Be careful not to drill all the way through!8) Before you attach the drawer front to the hinges, temporarily install all the screws to the correct depth. This will thread the holes so that the screws are much easier to drive when attaching the drawer front to the hinges. You can leave the two screws for the flip-out tray in place.9) Flip the hinges out to the 45 degree position. Start all four hinge screws into the drawer front, and screw them in far enough so they do not fall out. Use a right-angle philips screw driver to get them started. (You will include one of these $0.10 screw drivers in future shipments, or switch to allen head screws and allen wrench!)10) Carefully close the drawer front, so the screws don’t fall out. Crawl under the sink. While holding the drawer front against the cabinet with one hand, tighten all four screws most of the way, until the drawer front is still loose enough to adjust side-to-side. From the outside, adjust the drawer front side-to-side to align with the cabinet door below. Open the drawer front to the 45 degree position and fully tighten all four screws using the right angle philips screwdriver.11) Attach the knob or drawer pull, if desired.12) Attach the flip-out tray and tighten its screws.
